SPECIFICATIONS
| MODEL | PC13030HP |
| Optics Format | 1/3 inch |
| Image Circle | 3.6 mm |
| Field of View: Minimum | 20.0 x 13.5 mm |
| Field of View: Maximum | 65.0 x 42.1 mm |
| Working Distance Range with MINIMUM Object FOV | 76.2 mm |
| Working Distance Range with MAXIUM Object FOV | 0.0 mm |
| Angle of View | 25 degrees |
| F-Number | f/1.4 to close |
| Lens Camera Mount | C-Mount |
| Lens Length | 455.2 mm |
| Lens Diameter | 157.0 mm |
| Lens Mass | 6,673 g |
