VCXU-65M.R

VCXU-65M.R

High-Speed VGA Resolution CMOS Camera

  • 640 x 480 Pixels at 595 frames/sec
  • Global Electronic Shutter
  • 4.8 um Square Pixels
  • GigE Interface – Up to 100 meters via Standard Network Cable
  • Robust Mechanical Design for Factory Environment
  • Convenient M12 Connectors for Power and I/O






$ 499.00

Minus Quantity- Plus Quantity+

Specifications

MODEL VCXU-65M.R
Part Number 11175758
COLOR or Monochrome Monochrome
Interface USB 3.0
Total Pixels 6.2 Megapixel
Horizontal Resolution 3072
Vertical Resolution 2048
Pixel Size 2.4
Full Frame Rate 47 fps
Burst Mode Frame Rate 47 fps
Image Sensor Sony IMX178
Electronic Shutter Rolling shutter

Global reset shutter
Pixel Output Formats Mono8

Mono10

Mono12

Mono12 Packed
Optics Format 1/1.8 – inch
Lens Mount C-Mount
Digital I/O 1 input line
1 output line
2 general purpose lines
I/O Connector M8  (8-pin)



Supply voltage 5 VDC (via USB3.0 interface)
Current consumption 241 ma
Power Consumption 2.9 W



Operating Temperature  +5C to +65C
Operating Humidity 10% to 90% non-condensing
Protection Class IP-40
Conformity CE

RoHS

EAC
