SPECIFICATIONS
| MODEL | DFK 38GX542-a |
| COLOR or Monochrome | COLOR |
| Interface | GigE |
| Total Pixels | 16.13 MegaPixels |
| Horizontal Resolution | 5,320 Pixels |
| Vertical Resolution | 3,032 Pixels |
| Pixel Size | 2.74 um |
| Full Frame Rate | 7 frames/second |
| Image Sensor | Sony IMX542 |
| Electronic Shutter | GLOBAL |
| Pixel Formats | 8-Bit Bayer (RG) 12-Bit Bayer Packed (RG) 16-Bit Bayer (RG) YUV 4:2:2 YUV 4:1:1 |
| Lens Format | 1.1 inch |
| Lens Mount | C (CS Optional) |
| General Purpose I/O (GPIO) | 1 Opto-isolated Trigger Input 1 Open-Drain MOSFET Strobe Output |
| I/O Connector | Hirose 6-pin (HR10A-7R-4P) |
| Supply voltage | 9 VDC to 27 VDC or POE: 48 VDC to 56 VDC |
| Current consumption | 400 ma @ 12 VDC |
| Power Consumption | 4.8 Watts |
| Operating Temperature | -5 °C to 45 °C |
| Storage Temperature | -20 °C to 60 °C |
| Operating Humidity | 20 % to 80 % (non-condensing) |
| Storage Humidity | 20 % to 95 % (non-condensing) |
