Video Converters & Frame Grabbers

Digital machine vision cameras dominate the field of Machine Vision, but there are still numerous analog video sources in use throughout the world.

Using a Video-to-USB Converter or an Analog Frame Grabber from The Imaging Source, analog video sources can become usable in a digital environment.

ANALOG to DIGITAL VIDEO CONVERTERS

MODEL	FUNCTION	INPUT	INPUT PORTS	VIDEO FORMATS	OUTPUT	PRICE (USD)
DFG/USB2pro	Video-to-USB 2.0 Converter	PAL/NTSC RS170/CCIR	RCA (Cinch): 1 input Y/C (S-Video): 1 input Multiplexed	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	USB 2.0	$ 219
DFG/USB2propcb	Video-to-USB 2.0 Converter	PAL/NTSC RS170/CCIR	RCA (Cinch): 1 input Y/C (S-Video): 1 input Multiplexed	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	USB 2.0	$ 207
DFG/HDSDI (discontinued)	SDI-to-USB 3.0 Converter	HD-SDI	BNC: 1 input	HD-SDI: 1,920×1,080 @ 30 fps	USB 3.0	DISCONTINUED
DFG/USBtoHDMI	USB-to-HDMI Converter	USB 3.0	USB 3.0 Type A	3,840×2,160 @ 15 fps 1,920×1,080 @ 60 fps	HDMI	$ 275
DFG/HDMI	HDMI-to-USB 3.1 Converter	HDMI	HDMI: 1 input	1,920×1,080 YUY2 @ 60 fps 3,840×2,160 Y411 @ 30 fps 4,096×2,160 Bayer8 @ 30 fps	USB 3.1	$ 349

MODEL	VIDEO STANDARDS	SUPPORTED VIDEO FORMATS	ANALOG VIDEO INPUTS	COMPUTER BUS INTERFACE	COLOR VIDEO FORMATS	PRICE (USD)
DFG/SV1	PAL/NTSC RS170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	RCA (Cinch): 2 inputs Y/C (S-Video): 1 input Multiplexed	32 Bit - PCI 2.1	YUV 4:2:2, YUV 4:1:1, YUV 4:1:0 RGB 32, RGB 24, RGB 8	$ 219
DFG/SV1/LP	PAL/NTSC RS170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	RCA (Cinch): 2 inputs Y/C (S-Video): 1 input Multiplexed	32 Bit - PCI 2.1	YUV 4:2:2, YUV 4:1:1, YUV 4:1:0 RGB 32, RGB 24, RGB 8	$ 220
DFG/LC4	PAL/NTSC RS-170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	RCA (Cinch): 2 inputs Y/C (S-Video): 1 input Multiplexed	32 Bit - PCI 2.1	YUV 4:2:2, YUV 4:1:1, YUV 4:1:0 RGB 32, RGB 24, RGB 8	CALL
DFG/SV1/PCIe (discontinued)	PAL/NTSC RS-170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	RCA (Cinch): 2 inputs Y/C (S-Video): 1 input Multiplexed	32 Bit - PCI Express	YUV 4:2:2, YUV 4:1:1, YUV 4:1:0 RGB 32, RGB 24, RGB 8	DISCONTINUED
DFG/SV1/LP/PCIe	PAL/NTSC RS-170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	RCA (Cinch): 2 inputs Y/C (S-Video): 1 input Multiplexed	32 Bit - PCI Express	YUV 4:2:2, YUV 4:1:1,YUV 4:1:0 RGB 32, RGB 24, RGB 8	$ 220
DFG/MC4/PCIe	PAL/NTSC RS-170/CCIR	PAL: 768×576 @ 25 fps NTSC: 640×480 @ 30 fps	BNC: 4 inputs Parallel	32 Bit - PCI Express	YUV 4:2:2, YUV 4:1:1, YUV 4:1:0 RGB 32, RGB 24, RGB 8	CALL
